The Electric Spray Pro Application Skid is designed for roof washing, roof rejuvenation, and many other chemical spray applications. The components are designed to withstand harsh chemicals like bleach, acid, and solvents.  • Aluminum Pallet Skid 47”x60” at the bottom (solution tank hangs over a few inches on each side but it’s made to fit in a standard truck bed)• Choose 3 or 5 GPM 60 PSI 12v OR 115v Delavan, chemical resistant pump mounted neatly on an aluminum box. 12v pumps are the most commonly used pumps. You will need to supply a deep cycle marine battery which can be found at most automotive stores or even Walmart. The system comes with a box to fit a group 24 size battery. You simply charge the battery in the evenings using the provided charging system or you can pay a professional to wire it into your trailering system on your vehicle to charge. The 115v pump needs to be plugged into the customer’s power supply or a generator. These aren’t as common and are sometimes on back order since they are pumps we’ve had custom designed by Delavan for customer’s who have requested it. Please call before ordering a 115v to confirm lead times.  • Comes with an extra pump as a back up to quickly swap out on site. Even though these are chemical rated pumps, they will still have electrical issues from time to time that are commonly caused by low voltage and surges. Being such an inexpensive part, it usually makes more since to just replace the pump rather than trying to repair it.  NO WARRANTY ON PUMPS.  • 3 way valves installed on the suction and pressure side of the pump plumbed to allow for flushing the system, transferring solution into the tank on the system, priming the system and applying solution.  • Toggle switch installed on pump • Charging system installed for 12v pumps • Plug in neatly installed on the outside of the box so the system can be charged without opening the box.  • 18” aluminum reel with 300ft of 1/2” chemical resistant application hose ** Choose manual or electric hose reel ** • Application wand with poly trigger gun, stainless nozzles and cam lock system allowing the wand to be disconnected from the ball valve on the application hose. This gives you the option to fill buckets and pump sprayer with the application hose and neatly store your wand on the stainless holders installed on the outside of the box. • 100 gallon thick wall solution tank fully plumbed to the system • 100 gallon rinse tank fully plumbed with Hudson float valve for automatic water shut off. • Water fill line to connect a garden hose • Optional clear chemical metering manifold with premium Asahi metering valves. This will be neatly mounted to an aluminum stand on the system with the 3/4” water and bleach lines already plumbed and a free standing 1/4” soap line with filter installed. ** THIS FEATURE IS FOR SOFT WASHING AND ISN’T RECOMMENDED FOR ROOF REJUVENATION APPLICATIONS.  ** JUST OVER A TWO WEEK LEAD TIME ON AVERAGE  TO BUILD AND SHIP **

Read more less

** PICTURES SHOW A REMCO PUMP BUT THIS SYSTEM COMES WITH A 12V DELEVAN SOFT WASH PUMP** CHOOSE PUMP SIZE** This robust soft washing system consists of the highest quality components with no shortcuts taken.   INDUSTRY LEADING PUMP DESIGNED FOR SOFT WASHING Our Premium 12V Soft Washing System is available with your choice of a 5 GPM 100PSI or 7 GPM PSI Delevan Soft Wash Pump. You also have the option to add an extra soap valve.  • Neatly mounted on an aluminum plate with HD waterproof switch  • Pre-wired with 6ft of battery connection (positive & negative, 10 AWG)   CLEAR VIEW CHEMICAL METERING MANIFOLD WITH CHEMICAL RESISTANT VALVES & FLUSH/AUXILIARY VALVE  • Comes standard with 4 port clear view manifold (3/4”-1/2”-3/4”-1/2”) with a 3/4” through hole and end ports. The second 1/2” soap port is plugged with a 1/2” plug unless you add the second soap valve option. The clear material enables confirmation of product flow and helps with troubleshooting and locating leaks.• Our Premium 12V Soft Washing System comes with DOS/SM Series Metering Valves that are made of completely chemical resistant materials, seats and seals. These valves have a 180 degree handle turn for the most precise chemical metering.  • This soft washing system comes standard with a chemical resistant banjo 3-way valve with heavy duty stainless mounting pieces, ready to be bolted down. This valve is used for flushing your system after each use or for spraying chemicals other than bleach. This can also be used to transfer bleach onto your rig.    HEAVY DUTY ALUMINUM STAND  • Height - 30” • Width - 15.5"   COMES WITH SUCTION HOSES, FILTERS, UNISEALS, & HOSE CLAMPS • 50ft of 3/4” heavy duty suction hose  • 20ft of 1/4” poly braided soap hose  • 3 chemical resistant slotted PVC filters  • 1/4” soap filter (2 if you choose extra soap line option) • 2  uni-seals for the 3/4” bleach and water suction hoses to neatly pass through your poly tanks • Uni-seal for the 1/4” soap hose to neatly pass through your poly tank (2 if you choose extra soap line option)  • Pack of 20 heavy duty hose clamps to fit 3/4” and 5/8” hoses • 2 hose clamps to fit 1/4” hose (4 if you choose extra soap line option)    *** OPTIONAL 18” ALUMINUM RUGGED REEL OR TITAN HOSE REELS, 200ft of 5/8” SOFT JET SOFT WASH HOSE, & TRIGGER GUNF ASSEMBLY

Read more less

  **** PLEASE NOTE. The Pictures used are not of the current pump. Other than that, all other components will ne the same *** This is the most capable, compact spray system in the roof rejuvenation, agricultural and pest control industry. Suction Side  The 3 way Viton valve on the suction side gives the operator the option to draw from either the solution tank or their rinse line. Both the solution line and rinse line come with chemical resistant, slotted, poly filters. The solution line is 10ft long and the rinse line is 20ft long. Both are premium, 3/4” non collapsable suction hose. The solution line also comes equipped with a uniseal tank gasket to neatly secure the solution line and filter in your tank from the top side. Their are no metal fittings on the filters. Everything that goes into the tank is 100% chemical resistant poly. The rinse line can also be used to transfer chemicals from a bulk tank to a solution tank. If you select the metering manifold option for soft washing, the 3 way valve for flushing will be installed on the SH line of the metering manifold.  Pressure Side The bypass line is 10ft of 1/2” clear poly braid hose with a ball valve and cam lock system that connects to the top of the tank. The bypass line will circulate your chemical solution in a loop through the system while you are off the trigger and bypass any excess solution while you are on the trigger. This helps keep your batch mixed solution mixed throughout the application process.  Choose 3GPM or 5GPM 60 PSI Delevan Pump This system comes equipped with either a 3 GPM or 5GPM 60PSI pump powered by 12v or 115v.  These chemical rated Delevan pumps are pre-wired and neatly mounted to the aluminum box. 12v pumps are standard but we can have Delavan custom build AC versions of this pump. Sometimes this will extend the lead time if you choose the AC pump model.  COMES WITH AN EXTRA PUMP FOR BACK UP These electric pumps will fail over time (usually from low voltage or surges) but are pretty simple to replace. We send a back up pump with this system. *NO WARRANTIES ON PUMPS* HOSE REEL The Spray Pro 12V Application System comes with your choice of a full-frame 12” or 18” aluminum Rugged Reel with a stainless manifold. This reel is designed to hold up to daily use with corrosive chemicals.     APPLICATION HOSE  This professional sprayer system comes with either 200ft or 300ft of 1/2” Soft Jet Premium Chemical Resistant soft washing hose that is rated for 300 PSI. The 12” reel comes with 200ft and the 18” reel comes with 300ft. This robust application hose is UV resistant, non-marking, & lightweight. This hose meets RMA (Class B) oil resistance.  APPLICATION WAND  The wand consists of a ball valve, trigger gun, 18” wand and stainless J-rod with 4 stainless steel nozzles (0,15,25 and 40 degree 1/4 meg nozzles in #20 orifice. The zero degree nozzle is used to achieve the longest spray distance of approximately 40' while the 40 degree nozzle sprays the widest fan pattern for up close applications.  The application wand is able to be disconnected with a chemical resistant ball valve and camlock fitting and neatly mounted to the front of the Spray Pro 12V Application System. Being able to disconnect the wand allows for the operator to use our different wand set ups or even transfer chemicals to tanks and pump sprayers that are far from the spray system. NO SHORTCUTS ON COMPONENTS All fittings used on this professional grade spray application system including the hardware are either poly or stainless steel. We do not cut any corners on quality. This system is designed for daily, industrial use. Our system was designed by professionals to be used as a soft wash spray system, roof rejuvenation spray system, a pest control spray system or agricultural spray system but can also be used for many other solution spraying applications.    ASSEMBLY  The Electric Spray Pro Application System comes plumbed ready to use. All you need to supply is the tank and deep cycle marine batter if you choose the 12v option. You will need to install the provided bulkhead fitting to the top of your solution tank.

Read more less

Bare Truck Skid *all TIG welded aluminum by professional fabricators *full frame design for additional support and security (no formed panels or sheet metal) *full frame fork pockets for added support and safety during loading and unloading  *full frame shelves are self supporting which results in no flex/bounce while not relying on the truck bedside for support *narrower shelves are well within NTSB vehicle width guidelines while fitting all popular hose reel manufacturers *base is 48" wide, shelf height is 23" from bed floor to underside of shelf *10 year limited warranty

Read more less

Spray Pro Premium Mini Pressure Washing & Soft Washing Skid This is the ultimate mini skid in the pressure washing and soft washing industry. This compact layout (40” wide by 48” long at the bottom) allows for this skid to be placed in the back of small trucks.  Comes With: Heavy Duty Aluminum TIG Welded Skid With Fork Pockets Aluminum Shelves On Driver, Passenger, & Rear Side Aluminum Ladder Rack & Surface Cleaner Tray  7GPM 100PSI Remco Soft Wash Pump Neatly Mounted On An Aluminum Plate With A Switch, Battery Box & Charging System 3 Port Clearview Chemical Metering Manifold With Heavy Duty Aluminum Cover  5.5 GPM, 3000 PSI, Electric Start Honda GX390 With Gear Driven General Pump 55 Gallon Water Tank 55 Gallon Bleach Tank 7 Gallon Soap Tank 3 Full Frame ELECTRIC Aluminum Hose Reels With 200ft 1/2” Soft Wash Hose, 200ft 5/8” Garden Hose, & 200’ 3/8” High Pressure Hose.  18” Soft Wash Gun Assembly With Stainless J-Rod & Tips 36” Wand With 4 High Pressure Nozzles Float Valve For Water Tank Inlet Strainer For Water To Machine Water Tank Dump Valve Poly Strainers For Soft Wash System Group 27 Deep Cycle Battery & Fuse Panel  If you have any questions about this skid, please call, email, chat, or FB message us.  **THIS SKID HAS A LEAD TIME OF 4-6 WEEKS ON AVERAGE TO SHIP. Please call before placing your order to get an accurate lead time. There is a 20% Cancellation fee to cancel an order so please be prepared for this lead time and be 100% sure that it will work with your schedule.

Read more less

The Spray Pro Mini Pressure Washing & Soft Washing Skid is a super capable, compact, two in one pressure washing & soft washing system that can be truck, trailer or van mounted. This professional grade pressure washing and soft washing skid to allows you to clean efficiently with a small foot print. Absolutely no corners were cut when designing this system.  The Spray Pro Mini Pressure Washing & Soft Washing Skid includes: Aluminum pallet skid with fabricated back shelf 48”wide and 52” long measured from the bottom Approximately 650lbs dry Honda belt drive 5.5 GPM pressure washer (choose electric or pull start Two 55 gallon tanks for water and bleach with aluminum straps  7 gallon soap tank for surfactant with aluminum straps Asahi valve 4 Port soft wash metering system with clear manifold. 1” manifold with 3/4” and 1/4” chemical rated Asahi valves. Mounted neatly to aluminum stand. This allows you to select from or blend water, bleach, surfactant, and an additional valve and auxiliary suction hose for various solutions like bleach neutralizer, caustic degreasers, house wax, etc.  Banjo flush valve to flush the bleach valve with water after each use. This feature significantly prolongs the life of your soft wash metering manifold.  Delevan 7GPM 100PSI 12v soft wash pump mounted neatly to aluminum stand and pre-wired. Comes with an empty battery box to fit a group 24 deep cycle marine battery. Battery needs to be purchased locally. Down stream system with 3 Port DS PRO metering manifold with high quality Asahi valves for selecting or metering bleach and surfactant, and an additional auxiliary valve for various solutions like bleach neutralizer, caustic degreasers, house wax, etc.  Banjo micro flush valve to flush the DS Pro manifold bleach valve with water.  This feature significantly prolongs the life of your metering manifold 18” aluminum full frame reel with 3/4” stainless manifold  for soft washing hose & 12” aluminum full frame reel with 1/2” stainless manifold for high pressure hose 200’ of 5/8” soft wash hose & 200’ of 3/8” high pressure hose. 50’ of garden hose neatly stored on aluminum hose holder  Water drain system Hudson float valve system Poly soft wash gun and stainless nozzles Soft wash hose is set up on a camlock system so you can add hose as needed and switch attachments (extension hoses and extra trigger gun attachments sold separately). DN10 ball valve installed on high pressure hose Suttner high pressure trigger gun Matrix nozzle holder allows you to press red or blue buttons and quickly switch between M5DS twist nozzle and shooter tip.

Read more less

The Enchilada is a two in one soft washing and power washing skid that allows you to do a little bit of everything from one compact, highly capable, and premium system. 12" U-Frame Stingray™ Hose Reel (Soft Wash): 200 ft 1/2" Clear Braid Hose 12" U-Frame Stingray™ Hose Reel (Pressure Wash): 200 ft 3/8" Pressure Hose Bleach Tank: 50 Gallons Water Buffer Tank: 50 Gallons Soap Stinger Hose: 3/8 inch Reel Stand Lite w/ Extension: Lower Skid Unit: 42 inch Tank Straps: 3 inch Soap Metering Valve: 3/8 inch G.F. DN10 Bleach Metering Valve: 1/2 inch G.F. DN15 Soft Wash Pump: 5 GPM 12 volt 90 PSI Float Valve: 3/4 inch Hudson Power Washer: 5 GPM Belt Drive 3500 PSI Length: 45 inches Width: 58 inches Height: 49.5 inches Weight: 478 lbs

Read more less

Gas Powered Soft Wash & Pressure Washing Truck Skid. Compact footprint 48"x60" will fit short beds and allow for aftermarket ladder rack.Pressure washer: 5.7 gpm, 3000 psi gear drive with electric start Honda iGX390, setup to bypass to water tank.Soft Wash Pump: Gas powered Comet P40 or AR45 11.5 gpm, 290 psi, pull start engine.Hose reels: (3) matching aluminum frame, stainless steel internals 12" manual Hose: 200'x5/8" soft wash hose, 200'x5/8" water supply, 200'x3/8" HP hose non marking greyTanks: 100 gallon water capacity, 55 gallon SH, (2) 7 gallon soap tanksProportioning/metering system: Hydro-Mixer XL with dual soap valves, HD cover and manual flush valveSkid: 48"x60" with dual shelfs, fully welded HD aluminumMisc: soft wash gun, wand & JROD w/nozzles, HP gun, wand and 4 nozzles, SS quick connects on soft wash system, strainers/filters on all supply lines, SH resistant filter w/titanium clamp, float shutoff in water tank*12 volt deep cycle battery NOT included*-systems may vary due to availability of specific components. Approximate 2 week build time Add ladder rack and surface cleaner tray in options.

Read more less

Manufacturer/Model of certain parts may vary, for example...hose reel, hose color, spray wand type...We can guarantee all components and systems will meet our high quality standard and craftsmanship.      Pump:  Comet P40 or AR45 w/Honda engine Tanks:  (1) 55 gallon water tank, (1) 55 gallon chemical tank, (1) 7 gallon soap tank or (1) 100 gallon water tank, (1) 55 gallon chem tank, (2) 7 gallon soap tanks Hose reels:  (1) HD Summit, Titan or Kings reel for chemical spray hose, (1) HD Summit, Titan or Kings reel for water tank fill hose (hose reels are aluminum frames with stainless steel internals and swivel) Hose:  200' x 5/8" chemical resistant spray hose, 200' water tank fill hose with garden hose fittings Proportioning:  Hydro-Mixer XL w/bypass to pump, 3 metering valve-water, bleach, soap.   Pump Skid:  HD aluminum base plate Main Skid:  HD aluminum Misc Items:  Chemical resistant poly trigger, 18" sch 80 PVC wand, J ROD w/4 nozzles 0, 15, 25 and 40 degree Misc Parts:  Float shutoff in water tank, inlet strainer on water tank, all fittings PVC, poly or stainless steel Dimensions:  55 gallon tanks approx 40"x48"x48"H, 100 gallon water w/2 soap tanks approx. 48"Wx60"Lx48"H Options: Upgrade with Remote Rinse Module to save walking back to your rig to switch SH to water and shutoff surfactant.  Huge time saver! Upgrade to electric reels. **each system is custom made and may vary slightly**   Current lead time approx. 2 weeks.

Read more less

Manufacturer/Model of certain parts may vary, for example...hose reel, hose color, spray wand type...We can guarantee all components and systems will meet our high quality standard and craftsmanship.        Pump:  7.0 gpm Remco Fatboy on demand with inline fuse/circuit breaker, HD pressure switch Tanks:  (1) 55 gallon water tank, (1) 55 gallon chemical tank, (1) 7 gallon soap tank or 100 gallon water, 55 g. chemical and (2)-7 g. soap tanks Hose reels:  (1) HD stainless steel reel for chemical spray hose, (1) HD stainless steel reel for water tank fill hose Hose:  200'x1/2" chemical resistant spray hose, 100' water tank fill hose with garden hose fittings Proportioning:  Hydro-Mixer V4, 3 metering valve-water, bleach, soap.  Mounted to HD aluminum plate. Electrical:  HD wiring and on/off switch, on board weatherproof NOCO 10 amp charger, battery box included (battery supplied by customer) Skid:  HD aluminum Misc Items:  Chemical resistant poly trigger, 18" sch 80 PVC wand, J ROD w/4 nozzles 0, 15, 25 and 40 degree Misc Parts:  Float shutoff in water tank, inlet strainer on water tank, all fittings PVC, poly or stainless steel Dimensions:  55 gallon water tank 40"x48"x48"H, 100 gallon water tank 48"x60"x48"H **each system is built to order and may vary slightly   Current lead time approx. 2 weeks.
